Brand Gigabyte
Model GA-Z77-DS3H
Price 104.99
Listprice $109.99
|
Description
Supports 3rd Gen. Intel 22nm CPUs and 2nd Gen. Intel Core CPUs (LGA1155 socket). GIGABYTE 3D BIOS (Dual UEFI). Onboard mSATA slot for mSATA SSDs. PCI Express Gen 3.0 support. 2-way CrossFireX multi-GPU support. HDMI, DVI, RGB. High quality 108dB SNR HD audio. GIGABYTE 333 Onboard Acceleration (USB 3.0, SATA 3.0 & 3x USB Power). GIGABYTE On/Off Charge for USB devices….more info
Features
- CPU: Support for Intel Core i7/i5/i3/Pentium/Celeron processors in the LGA1155 package. Chipset: Intel Z77 Express Chipset
- Memory: 4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory. Dual channel memory architecture. Support for DDR3 1600/1333/1066 MHz memory modules. Support for non-ECC memory modules. Support for Extreme Memory Profile (XMP) memory modules
- Audio: Realtek ALC887 codec. LAN: Atheros GbE LAN chip (10/100/1000 Mbit).
- Support for AMD CrossFireX technology. Expansion Slots: 1 x PCI Express x16 slot, running at x16. 1 x PCI Express x16 slot, running at x4. 2 x PCI Express x1 slots. 2 x PCI slot.
- Storage Interface: 2 x SATA 6Gb/s connectors. 3 x SATA 3Gb/s connectors. 1 x mSATA connector. Support for RAID 0/1/5/10.
- Back Panel Connectors: 1 x PS/2 keyboard/mouse port/1 x D-Sub port/1 x DVI-D port/1 x HDMI port/4 x USB 2.0/1.1 ports/2 x USB 3.0/2.0 ports/1 x RJ-45 port/3 x audio jacks
- Internal I/O Connectors: 1 x 24-pin ATX main power connector; 1 x 4-pin ATX 12V power connector; 2 x SATA 6Gb/s connectors; 3 x SATA 3Gb/s connectors; 1 x mSATA connector; 1 x CPU fan header; 3 x system fan headers; 1 x front panel header; 1 x front panel audio header; 1 x S/PDIF Out header; 2 x USB 2.0/1.1 headers; 1 x USB 3.0/2.0 header; 1 x Clear CMOS jumper; 1 x serial port header; 1 x Trusted Platform Module (TPM) header
- USB: Up to 4 USB 3.0/2.0 ports. Up to 8 USB 2.0/1.1 ports.
Accessories
